How to Change the Belt on Dyson Vacuum Cleaner

The Dyson vacuum belt is a crucial component that needs to be replaced periodically to maintain your machine's performance.

The belt is usually located at the bottom of the vacuum, and its lifespan depends on how often you use your Dyson.

You can check the belt's condition by looking for signs of wear and tear, such as cracks or fraying.

A worn-out belt can cause your vacuum to produce strange noises or even break down completely.

To replace the belt, you'll need a replacement belt that matches the original one, which can be found in the Dyson manual or online.

To change the belt on your Dyson vacuum, you'll need a few tools and some basic information. A large flat blade screwdriver or a 20p coin is necessary to unscrew the retaining screws.

First, unplug the vacuum and lie it on its back. This will give you a clear view of the sole plate and the brushroll.

To remove the sole plate, turn the 3 plastic retaining screws (arrowed) a quarter of a turn anti-clockwise. You can use a screwdriver or a suitable coin for this.

With the sole plate off, the brushroll is now exposed. Make sure to remove any hair or carpet fibres from the brushroll before proceeding.

The new belt should be put on to the brushroll and refitted into the brushroll housing, ensuring the belt enters the belt slot.

To remove the old belt, you'll need to access the drive belt, which is usually located around the brushroll and motor spindle. This involves turning the vacuum cleaner over and removing the soleplate to access the belt.

You can remove the soleplate by undoing the locks with a flat head screwdriver, turning them 90 degrees, and then pulling the soleplate away. This will give you a clear view of the drive belt.

Start by removing the belt from the motor spindle using a flathead screwdriver to lift it up and back, then coax out the belt with your finger. You can also pull away the brush roll and pull the old belt through.

It's a good idea to keep a spare belt handy in case of a break, as belts can stretch or wear out over time. Regularly checking the belt for signs of wear and tear can help prevent this.

Changing the belt on your Dyson vacuum is a relatively simple process that can be done at home. You'll need to gather the necessary tools and a replacement belt designed specifically for your model.

To remove the old belt, slide one end off the brush roller and the other end off the motor shaft. This will give you access to the motor bearings, which can become tangled with hair and fibers over time.

Cleaning around the motor bearings is an important step to ensure your vacuum continues to run smoothly. Regularly checking the belt for signs of wear and tear or stretching can also help prevent future problems.

To replace the old belt, feed the new one through the assembly and put the brush roll back in place, making sure it's lined up correctly. The new belt should be put on the motor spindle by pulling it towards the motor with a flathead screwdriver.

Here's a quick checklist to ensure you've completed the process correctly:

By following these steps, you'll be able to change the belt on your Dyson vacuum and keep it running efficiently.

It's great to have a new belt for your Dyson vacuum, but let's not forget the importance of proper disposal of the old one.

The old belt should be disposed of according to local regulations, as mentioned in the "Disassembly and Removal" section.

You've now successfully changed the belt on your Dyson vacuum, and it's time to put everything back together.

Refer to the "Reassembly" section for a step-by-step guide on how to put the vacuum back together.

By following these steps, you should be able to get your Dyson vacuum up and running smoothly again.

Make sure to test the vacuum thoroughly after reassembly to ensure the belt is working properly, as mentioned in the "Testing the Vacuum" section.

It's always a good idea to keep a spare belt on hand, just in case the old one wears out again.
