Solar Water Heating Systems for Homes and Businesses

Solar water heating systems are a great way to harness the power of the sun to heat your water. They're a cost-effective and environmentally friendly alternative to traditional water heating methods.

A typical solar water heating system consists of a solar collector, a storage tank, and a heat exchanger. This setup allows the system to efficiently collect, store, and distribute solar-heated water.

These systems can be used for both residential and commercial applications, providing a reliable source of hot water for homes and businesses. They're especially useful in areas with high solar irradiance, such as the southwestern United States.

Some solar water heating systems can produce up to 80% of the hot water needed for a home or business, reducing the need for traditional water heating methods.

There are two main types of active solar water heating systems: direct circulation systems and indirect circulation systems.

Direct circulation systems are well-suited for climates where it rarely freezes, as pumps circulate household water through the collectors and into the home.

Expand your knowledge: Direct Exchange Geothermal Heat Pump

Indirect circulation systems, on the other hand, use a non-freezing, heat-transfer fluid that circulates through the collectors and a heat exchanger to heat the water flowing into the home.

These systems are popular in climates prone to freezing temperatures.

Here are the two main types of active solar water heating systems:

Antifreeze systems are a type of indirect circulation system, which use a mix of antifreeze and water to prevent freeze damage.

A differential controller is used to sense temperature differences between water leaving the solar collector and the water in the storage tank near the heat exchanger. This controller ensures that stored water always gains heat when the pump operates and prevents the pump from excessive cycling on and off.

The controller starts the pump when the water in the collector is about 8-10 °C warmer than the water in the tank, and stops it when the temperature difference reaches 3-5 °C.

If this caught your attention, see: Water Heater Storage Tank

Flat plate collectors have two horizontal pipes at the top and bottom, called headers, and many smaller vertical pipes connecting them, called risers. These risers are welded to thin absorber fins.

The type of glass used in flat plate collectors is almost always low-iron, tempered glass, which can withstand significant hail without breaking.

Unglazed or formed collectors are similar to flat-plate collectors, but they are not thermally insulated nor physically protected by a glass panel, making them less efficient when water temperature exceeds ambient air temperatures.

You might like: Heated Glass

Solar water heating systems can be designed to meet the needs of various households and businesses, with a typical system consisting of a collector, storage tank, and pipes.

A collector can be as small as 1 square meter or as large as 10 square meters, depending on the amount of hot water needed.

The storage tank is usually insulated to prevent heat loss and can hold anywhere from 100 to 1,000 liters of hot water.

In a well-designed system, the collector and storage tank are positioned to maximize the amount of sunlight the collector receives, often on a roof or a wall facing south.

A different take: Solar Water Heater Storage Tank

Passive systems are a great option for water heating, and they come in two basic types: integral collector-storage passive systems and thermosyphon systems. These systems are often less expensive than active systems, but they might not be as efficient.

Integral collector-storage passive systems work best in areas where temperatures rarely fall below freezing, and they're perfect for households with significant daytime and evening hot-water needs. They consist of a storage tank covered with a transparent material to allow the sun to heat the water.

Thermosyphon systems, on the other hand, are great for households with moderate hot-water needs. They work by heating water in a collector on the roof and then flowing it through the plumbing system when a hot water faucet is opened. Most of these systems have a 40-gallon capacity.

One type of passive system is the integrated collector storage (ICS) system, also known as a batch heater. It uses a tank that acts as both storage and collector, but it may require bracing if installed on a roof to support the weight of the water. This system is simple and less costly than plate and tube collectors, but it suffers from significant heat loss at night.

Intriguing read: How Do Water Pipes Run in a House

Another type of passive system is the convection heat storage unit (CHS) system. It's similar to the ICS system, but the storage tank and collector are physically separated and transfer between the two is driven by convection. This system typically uses standard flat-plate type or evacuated tube collectors, and the storage tank must be located above the collectors for convection to work properly.

Indirect systems offer freeze protection and typically overheat protection. They use a heat exchanger to transfer heat from the heat-transfer fluid (HTF) to the potable water.

The most common HTF is an antifreeze/water mix that typically uses non-toxic propylene glycol. This mix is effective at preventing freeze damage, but it has drawbacks.

One of the main drawbacks of antifreeze systems is that the glycol can degrade into acid if it gets too hot. This can provide no freeze protection and even damage the solar loop's components.

Antifreeze systems also require the HTF to be replaced every 3-8 years, depending on the temperatures it has experienced. Some jurisdictions even require more-expensive, double-walled heat exchangers.

In contrast, drainback systems use pure water as the HTF and are not subject to freezing or overheating. They work by circulating the HTF through the collector, driven by a pump, and then draining it back into a reservoir when the pump is switched off.

Here's a comparison of indirect systems with other types of solar water heating systems:

As you can see, indirect systems offer a good balance of freeze protection and overheat protection, making them a popular choice for solar water heating systems.

Solar water heating systems come in different forms, each with its own set of characteristics. Let's break down the key differences to help you decide which system is best for you.

The Active Direct system is a great choice if you're looking for a low-maintenance option. It's also lightweight and can survive freezing weather.

The Thermo­siphon system is another low-maintenance option that's also simple, with no need for ancillary control. It's perfect for those who want a hassle-free experience.

If you're looking to retrofit an existing storage tank, the Active Direct, Active Indirect, Drain­back, and Bubble Pump systems are all viable options. They can save you money and reduce waste.

Here's a summary of the key characteristics of each system:

The Bubble Pump system is also a great option if you want a system that's both low-maintenance and simple. It's perfect for those who want a hassle-free experience and don't need any extra storage tank.

Solar water heating systems are incredibly versatile, and one of their key advantages is their ability to operate effectively during the winter season. This makes them a great option for heating and cooling purposes in various industries.

ETCs can be used in pharmaceutical and drug, paper, leather, and textile industries, as well as in residential houses, hospitals, nursing homes, hotels, and swimming pools. They're also suitable for commercial applications like swimming pools.

ETCs can operate at a range of temperatures, from medium to high, making them suitable for solar hot water, swimming pool heating, air conditioning, and even solar cooking. This high operational temperature range also makes them ideal for industrial applications like steam generation and heat engine use.

Consider reading: Swimming Pool Solar Heating Covers

ETCs are particularly useful during the winter season, making them a reliable choice for heating and cooling purposes.

They can be used in various industries such as pharmaceutical, paper, leather, and textile production, as well as in residential houses, hospitals, nursing homes, hotels, and swimming pools.

ETCs can operate at a range of temperatures from medium to high, making them suitable for solar hot water, swimming pool heating, air conditioning, and even solar cooking.

Their high operational temperature range, up to 200 °C (392 °F), makes them ideal for industrial applications like steam generation and solar drying.

This high temperature range also enables the use of ETCs in heat engine applications, which is a significant advantage in certain industries.

Check this out: Sol-air Temperature

ETCs can be more useful than other solar collectors during winter season, which means you can save money on your heating bills.

Sunlight is free, so your hot water costs will be lower. You can also use ETCs for solar hot water, which is a great way to save on your water heating bills.

ETCs can operate at a range of temperatures from medium to high, making them suitable for various applications, including solar hot water and swimming pool heating.

By using ETCs, you can significantly reduce your energy bills, especially during winter months when heating is essential.

On a similar theme: How to save Aircon Electricity

When you install a solar water heating system, it's essential to work with an MCS-certified contractor to ensure you have a warranty. Solar water heating installed by an MCS-certified contractor comes with both workmanship and product warranties.

Typically, these warranties cover several years of workmanship and longer warranties for the solar collectors themselves. Always confirm the specific warranty terms with your installer before you go ahead with an installation.

Your installer should leave written details of any maintenance checks to carry out. Here are some key maintenance tasks to keep in mind:

Swimming pools are a great way to enjoy the outdoors during warmer months, but they can be a real energy drain if not properly maintained. Floating pool covering systems and separate solar thermal collectors (STCs) are used for pool heating.

Pool covers can significantly reduce heat loss by slowing down evaporation, which accounts for a lot of heat loss. Much heat loss occurs through evaporation, and using a cover slows it down.

In mild environments, unglazed plastic collectors are more efficient as a direct system for heating pool water. This is because they can withstand the mildly corrosive effects of chlorine in pool water.

A fairly simple differential temperature controller is used to direct the water to the panels or heat exchanger. This is a simple and effective way to optimize the solar pool heating system.

Collector panels are usually mounted on a nearby roof or ground-mounted on a tilted rack. This allows for maximum exposure to sunlight and optimal energy absorption.

A simple rule-of-thumb for the required panel area needed is 50% of the pool's surface area. This is a good starting point for sizing your solar pool heating system.

In cold climates, adding solar collectors to a conventional outdoor pool can extend the pool's comfortable usage by months. This is especially true if an insulating pool cover is used.

Most solar hot water systems are capable of heating a pool by as much as 10 °C for a wind-sheltered pool covered consistently with a solar pool blanket. This is a significant improvement over traditional heating methods.

Take a look at this: Solar Panels on Shed Roof

To get the best value for your money, get quotes from at least three different installers. This will help you compare prices and services.

Make sure the installers you choose are certified with the Microgeneration Certification Scheme (MCS). You can find a list of installers near you on the MCS website.

Under the question 'what would you like installed?' select 'solar thermal' when choosing a solar water heating system.

Your solar water heating system comes with a warranty, but it's essential to confirm the specific terms with your installer before installation.

Typically, you're covered for several years of workmanship and longer warranties for the solar collectors themselves.

Your installer should leave written details of any maintenance checks to carry out.

Have your system checked thoroughly every five years to flush the system and replace the fluid mix.

A shorter annual service check can give you peace of mind and cost less than a full service.

Leave your system running while on holiday, but make use of any 'holiday' functions.

Check your system control panel regularly for any warnings and contact your installer if any issues occur.

The cost of a solar water heating system can be substantial, with prices ranging from £6,000 to over £14,000, depending on the size of the system and the type of collectors used.

In some countries, government incentives can offset these costs, such as the Renewable Energy Credits system in Australia, which offers a subsidy.

The payback period for solar water heating systems can vary greatly, from 4.2 years in Brazil to 18.2 years in the United Kingdom, depending on factors like insolation and household hot water use.

Here's a rough idea of the costs and payback periods for solar water heating systems in different countries:

Solar water heating systems can provide significant savings on your hot water bills, with average savings of around 50 kWh per month.

Solar water heating is a global phenomenon, with many countries embracing its benefits. China is the largest user of solar thermal power, accounting for over 75% of the world's total in 2022, with a capacity of 396.4 GWth.

The European Union (EU) is also a significant player, with a capacity of 63.2 GWth in 2022, ranking second globally. The EU's solar thermal power usage has been steadily increasing, with a notable jump from 47.5 GWth in 2013 to 63.2 GWth in 2022.

Other notable countries using solar thermal power include Turkey, the United States, and Germany, which have capacities of 19.2 GWth, 18.4 GWth, and 15.8 GWth, respectively, in 2022.

On a similar theme: Central Ac Unit Power Consumption

In the Mediterranean region, Israel leads the way in solar water heating, with 85% of households using solar thermal systems, saving the country 2 million barrels of oil a year.

Israel's success can be attributed to the government's requirement in 1980 to install solar water heaters in all new homes, except high towers with insufficient roof area. This initiative made Israel the world leader in solar energy per capita.

The NerYah Company, Israel's first commercial manufacturer of solar water heating, was launched in 1953 by Levi Yissar. He built the first prototype Israeli solar water heater in response to a fuel shortage in the 1950s.

Spain followed Israel's lead in 2006, requiring the installation of solar water heating systems in new buildings. This made Spain the second country to do so, after Israel.

In Europe, Germany tops the list in solar thermal heating, with a capacity of 12,055 MWth in 2013. The country's commitment to renewable energy has driven its growth in solar thermal systems.

Here's a list of the top 5 countries in Europe for solar thermal heating in 2013:

In Asia, Japan started marketing solar water heating systems after 1960. China has also made solar water heating systems popular, with basic models starting at around 1,500 yuan (US$235), around 80% less than in Western countries for a given collector size.

At least 30 million Chinese households have a solar water heating system, thanks to efficient evacuated tubes that allow the heaters to function even under gray skies and at temperatures well below freezing.

In Canada, there are specific standards in place for solar collectors and systems. The CAN/CSA-F378 Series 11 standard applies to solar collectors.

One of the key standards for packaged solar domestic hot water systems in Canada is the CAN/CSA-F379 Series 09 standard. This standard ensures that these systems meet certain requirements for safety and performance.

Canada also recognizes the SRCC Standard 600, which sets a minimum standard for solar thermal concentrating collectors.

Solar water heating is a great way to reduce your carbon footprint, as it uses renewable energy and cuts down on your reliance on fossil fuels for heating.

The environmental impact of solar water heating is a complex issue, but studies have shown that the energy used in manufacturing is recovered within the first 2-3 years of use in southern Europe.

In the UK, the energy payback time for a direct system is reported as only 2 years, which is a significant improvement over other forms of renewable energy.

A test system in Italy produced about 700 kg of CO2, considering all the components of manufacture, use and disposal.

However, maintenance was identified as an emissions-costly activity when the heat transfer fluid (glycol-based) was replaced, but the emissions cost was recovered within about two years of use of the equipment.

In Australia, life cycle emissions were also recovered, with a tested SWH system having about 20% of the impact of an electrical water heater and half that of a gas water heater.

Here's a rough breakdown of the energy consumption for a solar water heating system:

It's worth noting that the degree to which gas or electricity is used to supplement the sun can significantly impact the CO2 emissions saved.
