Mastercool Swamp Cooler Wiring Diagram Complete Guide

Mastercool swamp coolers are a popular choice for cooling homes and businesses in dry climates. They're relatively easy to install and maintain.

The Mastercool swamp cooler wiring diagram is essential for getting your unit up and running. It's usually found in the unit's manual or online.

A typical Mastercool swamp cooler wiring diagram includes connections for the thermostat, compressor, and fan. You'll also see wires for the unit's lights and any additional features.

To ensure your unit runs efficiently and safely, follow the wiring diagram carefully.

For another approach, see: Swamp Cooler Switch Wiring

The electrical wiring diagram for your MasterCool swamp cooler is a crucial document to have, but unfortunately, it's not always easy to find. You can check the Maintenance Section of the Champion MasterCool ADA35 Owner's Manual, which might have a wiring diagram or at least some information on electrical installation.

A wiring diagram can help you understand how the 24V low-voltage control kit is connected to the various components of the cooler. This is especially important if you're trying to reverse-engineer the system, like Brock Tice did. He was able to confirm that the 24V supply is used for control, not for driving the motors directly.

A fresh viewpoint: Why Is My Swamp Cooler Not Blowing Cold Air

The 24V supply is likely stepped down using a transformer, which is why Brock's multimeter reads ~0 in DC mode. This is a good thing, as it makes the system safer for control panels.

If you're trying to drive the 24V lines, you'll need to use a relay board, as Brock Tice already ordered. This will let you handle the power safely and efficiently.

Here's a quick rundown of the terminals you'll find on the cooler:

Make sure to check the voltage between the 24V connection and COM to ensure you have the correct 24VAC.

Before starting the installation, make sure to read and follow all installation and operating instructions to avoid personal injury and damage to property.

It's crucial to comply with local building and safety codes, and electrical installations should only be performed by qualified personnel.

The control system is designed to work with an evaporative cooler that has a 2-speed blower and a water pump, and will also operate a water purge pump or valve if equipped.

Broaden your view: How Do U Fix a Swamp Cooler Pump

You'll need the following components to complete the installation: a Wall Control Thermostat, a 2-Speed Evaporative Cooler Control, a Wire Nut for common Earth connection, a Spare 3.15 Amp fuse for control, and a jumper wire for Link to N-Link (to be used only when both Fan and Pump voltages are the same).

Additional items you may need include screws or bolts for mounting the Appliance Control Box and Wall Control, wiring for connection between power supply and Appliance Control Box, Wall Control and Appliance Control Box, and between Appliance Control Box and the cooler connection box, conduit, and watertight connectors to protect all wiring.

To ensure a safe installation, disconnect electrical power to the system at the main fuse or circuit breaker before starting the installation.

Here are the steps to install the Appliance Control Box:

1. Determine a suitable place to install the Appliance Control Box, mark the location of the three mounting points, and drill pilot holes for the mounting screws.

2. Decide which knockout locations will be used for the system wiring and cut out the required knockouts using a suitable tool.

3. Mount the box using suitable screws and install conduit and connections, ensuring a watertight seal.

4. Run wiring according to local and national electrical codes to suit the installation.

5. Connect the wires in accordance with the wiring diagram on the next page or inside the Appliance Control box lid.

Remember to use the jumper wire between Link and N-Link only when fan and pump voltages are the same.
